| Material: | PA 6.6 with 30% glass fibre |
| Part weight: | 3.5 g |
| Mould: | Hot runner mould integrated in fully automated production line |
| Hot runner system: | Direct side gating. Radial nozzle |
| Cavities: | 12 |
| Material: |
PC (coloured surface) ABS (white back layer) ABS (black support frame) |
| Part weight: | 60.5 g |
| Mould: | 3-component rotational mould |
| Hot runner system: |
Coloured surface and back layer: valve gating with electric drive units Support frame: open gating with single tip on auxiliary sprue |
| Cavities: | 1+1+1 |
| Material: | PBT ULTRADUR with 30% glass fibre |
| Part weight: | 2 g |
| Mould: | Fully automated production cell with integrated injection moulding machine |
| Hot runner system: | Slim nozzles in linear arrangement with small distances between cavities |
| Cavities: | 12 |
| Material: | PA with teflon additive (body), PA with ceramic and glass fibre (tweezer blade) |
| Part weight: | 0.18 g (body), 0.1 g (tweezer blade) |
| Mould: | 2-component rotational mould with full and partial hot runner system |
| Hot runner system: | Slim nozzles for direct gating (body). Partial hot runner with gating on subrunner (tweezer blade) |
| Cavities: | 24 |
| Air by-pass valve housing | Flap for air by-pass valve | |
| Material: | ABS | ABS |
| Hot runner system: | Direct side gating. Linear nozzles. | Direct side gating. Linear nozzles. |
| Cavities: | 8 | 16 |
| Material: | PCTA |
| Hot runner system: | Direct side gating. Radial nozzles |
| Cavities: | 4 |
